Model Number: LTT021
Description: Front Thermal Imaging Clip-on
Sensor Parameters
Sensor Type: Uncooled Vanadium Oxide
Sensor Resolution (pixels): 640 × 512
Sensor Pixel Pitch (micrometers): 12
Noise Equivalent Temperature Difference (milli-Kelvin): ≤ 40
Frame Rate (Hertz): 50
Optical Parameters: Clip-on Mode
Objective Focal Length (millimeters): 50
Objective Field of View (H×V), degrees: 8.8° × 7.0°
Objective Focus Range: 5mm~∞
Exit Pupil Distance: 10mm
Dioptric Adjustment: ±5
Electronic Magnification: 1 to 4
Matched Magnification: 1 to 8
Weight (grams): <550
Dimensions (millimeters): 140× 65 × 78
Display Parameters
Display Screen Type: OLED
Resolution: 1024 × 768 (0.39 inch)
Color Palette:
White-hot/Black-hot/Iron Red/Glowbow/Sepia/Red-hot/Green-hot
Function
Wi-Fi / APP: Support
Photo / Video: Support
Automatic Design Video: Support
Operating Characteristics
Battery: CR123A*2
Maximum Working Time (22ºC), hours*: 4
Operating Temperature Range, °C: -20~+50
External Power Supply: 5V (Type C)
Maximum Recoil Force of Rifled Weapons, g/s²: 1000
Protection Level: IP67
Connection Thread: M57x0.75
